Magnetic Destoner
Introducing the Oromineral Magnetic Destoner, Model WHIMS-002, a state-of-the-art industrial solution designed to efficiently separate magnetic particles from various materials. Engineered with high-performance magnets and robust construction, our magnetic destoner ensures precision and reliability in even the most demanding applications. Suitable for a wide range of industries, including mining, ceramics, chemicals, and food processing, the WHIMS-002 is customizable to meet your specific requirements.
Technical Specifications:
| Parameter | Specification |
|---|---|
| Model | WHIMS-002 |
| Magnetic Field Strength | Up to 2.0 Tesla (customizable) |
| Feed Particle Size | ≤ 3mm (dependent on model) |
| Capacity | 1-50 t/h (dependent on model) |
| Power Consumption | 5-50 kW (dependent on model) |
| Operating Temperature | 0-60°C |
| Operating Pressure | Atmospheric to 0.6 MPa (dependent on model) |
| Material of Construction | Stainless Steel 304/316, High-Grade Magnets, Rubber Linings (customizable) |
| Dimensions (L x W x H) | Varies by model (e.g., 2000mm x 1500mm x 1800mm) |
| Weight | Varies by model (e.g., 5000 kg) |
| Control System | PLC-Based Automation with Touchscreen Interface (optional) |
| Certifications | ISO 9001:2015, CE, ATEX (for hazardous environments, optional) |
Key Features:
- High-Performance Magnets: Provides strong magnetic field strength to efficiently separate magnetic particles.
- Customizable Design: Tailored to meet specific application needs, including material of construction and magnetic field strength.
- Robust Construction: Built with stainless steel 304/316 and high-grade magnets for durability and longevity.
- Large Capacity: Handles a wide range of capacities, from 1 to 50 tons per hour, depending on the model.
- Versatile Applications: Suitable for mining, ceramics, chemicals, food processing, and other industries.
- User-Friendly Control System: PLC-based automation with a touchscreen interface for easy operation and monitoring (optional).
- Certified Quality: Complies with ISO 9001:2015, CE, and ATEX certifications for hazardous environments (optional).
Custom Solutions:
At Oromineral, we understand that every application is unique. Our team of experts is dedicated to providing customized solutions to meet your specific requirements. Whether you need a magnetic destoner with a customized magnetic field strength, material of construction, or capacity, we have the expertise to deliver.
Contact Us:
For more information about the Oromineral Magnetic Destoner, Model WHIMS-002, or to discuss your custom needs, please contact our sales team at sales@oromineral.com or call us at +86 13068619480. We look forward to helping you find the perfect solution for your application.
